500W Class D 2 Channel Full Range Mini Amplifier - Compact Hi-Fi Audio Power Amp for Home Theater, Car Audio, and Studio Monitors

2 Channel Full Range Class D Amplifier

2 Channel Class D Full Range Technology
2-Ohm Stereo load Capability
Marine Grade Nickel Plated RCA connectors
Variable 12db Low-pass crossover
Bridgeable Outputs @ 4-Ohms load
Marine Grade Conformal Coated Double Sided PCB
Compatible with any 4/2-Ohms Subwoofer
Output Power @ 14.4 VDC, 2-Ohms 2 x 250W
Output Power @ 14.4 VDC, 4-Ohms 2 x 125W
Output Power @ 14.4 VDC, 4-Ohms 1 x 500W
Power Supply Input Voltage 12.0VDC to 14.8VDC
THD (1KHz @ 4-Ohms): 0.04%
Bandwidth (-3 dB): 18Hz - 22KHz
Damping Factor (1KHz @ 4-Ohms): 100
S/N ratio (as weighted @ 1 Volt): 99db
Input Sensitivity: .0.2MV - 6V
Minimum Load Impedance: 2-Ohms
Low-Pass filter range: 15Hz - 300Hz
Sub-Sonic Filter Range: 50Hz - 300Hz
